NovaDeck 16mm: Technical Specifications and Installation Guide
Designed for 12mm wet underfloor heating pipe at 150mm centres, this 16mm cement-faced XPS panel offers a slim retrofit solution without a conventional thick screed layer. The high-strength XPS 300 core, factory-routed channels and tough cementitious face help installers create an efficient, consistent pipe layout on a suitable structural subfloor.
Technical specifications
| Panel dimensions | 1200 x 600 x 16mm |
|---|
| Coverage per full board | 0.72m² |
|---|
| Suitable pipe diameter | 12mm |
|---|
| Pipe spacing | 150mm centres |
|---|
| Core | High-density extruded polystyrene (XPS 300) |
|---|
| Strength at 10% compression | 300 kPa |
|---|
| Surface | Fibreglass mesh-reinforced cementitious coating |
|---|
| Thermal conductivity | Confirm value for the 16mm NovaDeck variant with Novatherm |
|---|
| Reaction-to-fire classification | Confirm Euroclass rating for the 16mm NovaDeck variant with Novatherm |
|---|
Key benefits
- Correctly sized channels for 12mm underfloor heating pipe at 150mm centres
- Low-profile 16mm panel for retrofit work and projects with limited floor build-up
- Reinforced cement face suitable for direct tiling with the correct adhesive
- XPS insulation core with 300 kPa compressive strength
- Pre-formed pipe routes with returns to reduce on-site preparation
- Lightweight, easy-to-handle 1200 x 600mm boards
Suitable subfloors and fixing
Install onto a clean, flat, level and fully supported substrate. Suitable bases include cured concrete or screed, structural plywood or cement fibreboard; traditional timber floorboards may need overlay boarding. Use an appropriate combed flexible tile adhesive over suitable solid substrates and manufacturer-approved mechanical fixings on timber. Check moisture conditions and use a damp-proof membrane where required by the floor design.
Floor finishes
Tiles and natural stone can be fixed to the cementitious panel surface using a suitable flexible tile adhesive and the flooring manufacturer’s instructions. Vinyl, carpet, engineered wood and laminate require the specified levelling compound or separating layer. Follow the current Novatherm installation manual for preparation, curing times, floor-finish suitability and commissioning.
Professional trade support
Underfloor Heating Trade Supplies provides installer-focused advice, trade pricing and support with compatible pipework and system components. Contact our team if you need help selecting the correct board thickness, pipe size or quantities for your project.
